Ezcap321 GameLink RAW

– 2160p30, 1080p120, 1440p60 HDMI input, pass-through.
– 1080p120, 2160p30 and 1440p60 recording.

– RGB real color video format up to 1080p30.

– Latency less than 50ms.

– UVC standard, manual driver installation is not needed.

– Supports most of third party video capture softwares.
– USB 3.1 super fast speed.
– With Line In port.

– Supports most of third party video capture softwares.
– Type-C USB 3.1 Gen1 super fast speed.
– Recording party chat with game video by party chat link cable.

Availability: In Stock
Support 2160p30 / 1080p120 Input Output Capture and Live

The best game capture live card that supports 2160p30 and 1080p120 input, output, capture and live broadcast. No chromatic aberration, no delay, no need to manually install the driver, built-in line audio input, connecting mixers or other audio sources is easy. Equipped with self-developed collection and live broadcast software -ezcap Link, no setting is required, and it can be used immediately.

Capture and Live Video for Game Consoles

Capture and Live for PC Games

Live for HD Cameras

Capture and Live for Mobile Games

  • Interface: Type-C USB 3.1 Gen1
  • Video Input: HDMI 2.0
  • Audio Input: HDMI, Line In (3.5mm TRS)
  • Video Output: HDMI 2.0
  • Audio Output: HDMI
  • Max. Pass-Through: 2160p60 HDR, 1440p144, 1080p240
  • Max. Recording: 1080p120, 2160p30
  • Supported Resolution: 2160p, 1440p, 1080p, 720p
  • Output Video Format: YUY2, NV12, RGB
  • Recording Resolution and Max FPS:  3840x2160 - NV12/30; 2560x1440 - NV12/60, YUY/50; 1920x1080 - NV12/120, YUY/60, XRGB/30; 1280x720 - NV12/60, YUY/60, XRGB/60.
  • LED status indicator: Red-power, Blue-HDMI signal, mixing slow flash-software detectived.
  • System Requirement:
Windows 10 x 64 Laptop: For 4Kp30 or 1080p120 recording: Intel Core i7-7700HQ or above, NVIDIA GeForce GTX1050 Ti or above, 8 GB RAM. For 1080p60 recording(4Kp60 HDR pass-through supported): Intel Core i7-4810MQ, NVIDIA GeForce GTX 870M or above, 8 GB RAM. Desktop: For 4Kp30 or 1080p120 recording:Intel Core i5-6XXX / AMD, Ryzen 3 XXX or above, NVIDIA GTX 1060 / AMD RX 5700 or above, 8 GB RAM. For 1080p60 recording:Intel Core i7-3770 recommended, NVIDIA GeForce GTX 650 / AMD Radeon R7 250X or above, 4 GB RAM. Mac OS High Sierra 10.15 and above. For 4Kp30 or 1080p120 recording: iMac 2019: 3.2GHz 6-core Intel Core i7, Radeon Pro 555X with 2GB of GDDR5 memory, 16GB of 2400MHz DDR4 memory. MacBook Pro 2018: 2.6GHz 6-core Intel Core i7, Radeon Pro 560X with 4GB of GDDR5 memory or above, 16GB of 2400MHz DDR4 memory.
  • Package Contents: ezcap320 GameDock Ultra,  Type-C cable, Type-C to USB 3.0 cable, Manual
  • Dimensions: 99 x 99 x 23 mm
